| SPECIFICATIONS | KBD-2023D | |
| Port | Network: RJ45. Serial Port: RS422, RS232 | |
| Interface | RS422, RS232, RJ45 | |
| Decoding | H.265, H.264 | |
| Display | TFT LCD (5-inch) | |
| Resolution | 1920 x 1080@30fps | |
| Joystick | 4D ( up, down, left, right, zoom+, zoom- ) | |
| Prompt tone | ON/OFF | |
| Power Supply | DC12V 2A ±10% | |
| Power Consumption | 5W | |
| Working Temperature | -10°C ~ 55°C | |
| Storage Temperature | -10°C ~ 60°C | |
| Dimensions (WxLxH) | 340 x 268 x 140mm | |
| Weight | 900g | |
| Upgrade | WEB Upgrading |
SOUNDVISION KBD-2023D
SKU : SOUNDVISION KBD-2023D
เครื่องควบคุมกล้องแบบ Network (IP-Based) SOUNDVISION KBD 2023D a network (IP Based) PTZ camera controller, 5-inch LCD solution 1920 x 1080P H.264/265 stream, super wide viewing angle, display effect is excellent characters are delicate and clear. IP keyboard supports ONVIF protocol, compatible with 99% of PTZ cameras. Easy operation PTZ Cameras can be perfectly controlled.
฿17,900
฿0
฿17,900
ราคาสมาชิก
฿0
ราคาสมาชิก
฿0
จำนวน
ขอใบเสนอราคา
รายละเอียดสินค้า
สเปค
ดาวน์โหลด
- Support ONVIF protocol, with the independent IP address in IP mode.
- 5-inch LCD screen, image decoding, real-time monitoring.
- RJ45, RS422, RS232 control interfaces.
- Support software function control of conference cameras.
- Support Adopt high-quality variable speed 4D joystick control.
- Support preset patrol pattern and AB scan.
- Support IE browser to add camera configuration parameters.
- The camera position you set up to 99 preset Max.
- Support standard POE power supply.
