SOUNDVISION DMC-8800N

FEATURE

• ADI SHARC 21489 processor

• Analog input Channels : 8 | Analog output Channels : 8

• 8 balanced microphone or line level inputs on Terminal Block connectors.

• 8 balanced line level outputs on Terminal Block connectors.

• Audio interfaces on RJ-45 connectors.

• Built-in 2-in 2-out USB soundcard support Web video conference for recording and music playback.

• Supports Apple iOS and MS Windows operating systems.

• Supports adaptive echo cancellation (AEC), adaptive feedback control (AFC), automatic gain control (AGC), automatic mixer control (AMC), automatic noise suppression (ANS)

• Up to 16 settings can be preset providing 5 options parametric, Low-shelf, High-shelf, Low-pass, High-pass.

• Definable GUI (Graphical User Interface) for managing and configuring multiple units.

• Each input supports 8 band parametric equalizer (PEQ), signal generator, compressor, expander, ducker, and 48V phantom power.

• Each output supports 12 band graphic equalizer (GEQ), audio crossover, delayer, limiter.

DIAGRAM
