This system is the perfect combination of all digital intelligent control technology,which can be connected with external cameras, tracking and speaking leaders.The integrated recording device can realize the whole meeting record backup, which is easy to operate and install. Built in high-performance CPU and anti-interference circuit design to eliminate external signal interference. Imported components ensure the quality of voice transmission, high fidelity and clear voice

Features

• Full digital high fidelity circuit development and design.
• Built in high-performance CPU, stable system and fast computing speed
• The host adopts LCD display and the menu operation is simple, intuitive and user-friendly.
• Supports up to 50 units for 8 Pin Cable Mic Units or Support up to 40 units for RJ45 Cable Mic Units
• Multiple meeting mode: FIFO mode, Amount limited mode, Chairman mode and Full open mode
• Unique high fidelity audio processing circuit to improve the clarity of the whole system.
• Recording function, supporting USB flash disk below 32g
• It has central control code RS-232 interface and bidirectional code sending function. The connection between the host and camera adopts RS232/RS485 communication protocol.
• Safety standards. The conference unit is powered by the system host, with the working voltage of AC110-240V/50-60Hz

Specification

• Input/Output: 8P-DIN*4
• Input: RCA*1
• Output:XLRM*1(Balance) RCA*2   6.35mm*1
• Input Voltage: AC110-220V 50-60Hz
• Power Consumption:120W(Max)
• Frequency Response: 30Hz-18KHz
• Gain: 0dB
• S/N Ratio: 100dB
• Ground noise: -86dB
• Host Size(W*H*D): 483*292*85mm
• Packing(W*H*D): 515*390*160mm
• W/G.W: 4.35KG/6.15KG
• Color: Black

Connection Diagram

Package Content

• HOST *1
• 220V Power Cable *1
• User Manual*1
• Cable 10m for main unit*1
