| Power Source | 100 - 240 V AC 50/60 Hz |
|---|---|
| Rated Output | 120 W (Speaker Output) |
| Power Consumption | 170 W (rated output), 45 W (1/8 of rated output) |
| Frequency Response | 40 Hz to 20 kHz |
| Distortion | 1 % or less at 1 kHz (20 kHz LPF (AUX-0025)) |
| Tone Control (only mobile app) | Bass: ±10 dB at 100 Hz Treble: ±10 dB at 10 kHz |
| Signal to Noise Ratio | 70 dB or more |
| Audio Input | LINE IN: -10 dB (1*), 10 kΩ, ø3.5 mm stereo mini-jack BLUETOOTH: 5.0 SBC/AAC Wi-Fi: IEEE 802.11 b/g/n 2.4GHz LAN: 10/1 QOM Ethernet, RJ45 USB (storage): USB 2.0 Type-A port (*2) USB (PCI: Micro-USB port EXT AMP IN: 40 dB (*1) (100 V line), 65 kΩ, transformer balanced, removable terminal block (5 pins) |
| Audio Output | SPEAKER OUT: Low impedance (4-16 Ω)/High impedance (100 V line/total 83Ω) selectable. removable terminal block (5 pins) LINE OUT: -10 dB (*1), 10 kΩ, ø3.5 mm stereo mini-jack |
| Audio Format | FLAC/MP3/AAC/AAC+/ALAC/APE/WAV |
| Sampling Frequency | Decoding up to 192 kHz/24 bits |
| Control Input | CTRL IN: No-voltage make contact input, open voltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (2 pins) |
| LED Indicators | NET (Green), Bluetooth (Green), USB (Green), LINE (Green), SIGNAL (Green), PEAK (Red), PROTECT (Red), STANDBY (Orange), POWER (Green) |
| Operating Temperature | 0 to +40 |
| Operating Humidity | 90 %RH or less (no condensation) |
| Finish | Front case: Surface-treated steel plate, black, paint Rear chassis: Surface-treated steel plate |
| Dimensions (W x H x D) | 210 x 44 x 200 mm (excluding projection) |
| Weight | 1.8 kg |
| Accessories | Removable terminal plug (5 mm, 5 pins)..... 1 Removable terminal plug (3.8 mm, 2 pins).... 1 Power supply cord (2 m (6.56 ft)).... 1 External antenna ..... 2 |
| Option (*3) | Half width blank panel: MB-15B-BK (for rack mounting one VA-120DPB unit) |
(*1) 0 dB = 1V
(*2) A USB 2.0-compatible FAT32-formatted flash memory device of up to 32 GB in capacity can be used.
(*3) When using the optional MB-15B-BK, use the bracket mounting screws supplied with this unit.
* The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by TOA Corporation is under license. Other trademarks and trade names are those of their respective owners.
