ATEN VE1801EUT
SKU : ATEN VE1801EUT
จำนวน
คำอธิบายสินค้าแบบย่อ
อุปกรณ์ส่งสัญญาณ HDMI HDBaseT-Lite ชนิดเต้ารับติดผนังมาตรฐานยุโรป (EU Wall Plate ขนาด 1-gang) ส่งสัญญาณภาพความละเอียดสูงระดับ 4K ได้ไกลสูงสุด 40 เมตร และ 1080p ได้ไกลสูงสุด 70 เมตร
ATEN VE1801EUT
HDMI HDBaseT-Lite Transmitter with EU Wall Plate
Description:
The ATEN VE1801EUT is a transmitter designed to reliably send 4K signals up to 40 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. With EU Wall Plate design, the VE1801EUT can be conveniently mounted in a one-gang junction box. For HDMI signal transmission, it supports 3D, Deep Color, and embedded HD lossless audio formats.
The compact wall plate design does away with bulky cables, allowing a neat and convenient installation. Therefore, VE1801EUT is specifically designed for use in meeting rooms, digital educational environment or wherever needed to meet application requirements.
Features:
Extends HDMI signals with superior video quality over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable (4K up to 40 m, 1080p up to 70 m).
HDMI 1.4 (3D, Deep color, 4K); HDCP 2.2 compliant.
Designed to mount in a one-gang junction box.
Supports RS-232 channel transmission.
Consumer Electronic Control (CEC) allows interconnected HDMI devices to communicate and respond to a single remote control.
HDBaseT Anti-jamming - resists signal interference during high-quality video transmission using HDBaseT technology.
LED indication of device status.
Built-in 8KV / 15KV ESD protection.
Plug-and-play operation.
Specifications:
| Model | VE1801EUT |
| Video Input Interfaces | 1 × HDMI Type A Female (Black) |
| Impedance | 100 Ω |
| Max. Data Rate | 10.2 Gbps (3.4 Gbps per lane) |
| Max. Pixel Clock | 340 MHz |
| Compliance | HDMI (3D, Deep Color, 4K), HDCP Compatible, Consumer Electronics Control (CEC) |
| Max. Resolutions / Distance | 4K @ 35 m (Cat 5e/6) / 40 m (Cat 6a / ATEN 2L-2910 Cat 6) 1080p @ 60 m (Cat 5e/6) / 70 m (Cat 6a / ATEN 2L-2910 Cat 6) *(4K supported: 4096 × 2160 / 3840 × 2160 @ 60Hz [4:2:0]; 4096 × 2160 / 3840 × 2160 @ 30Hz [4:4:4])* |
| Audio Input | 1 × HDMI Type A Female (Black) |
| RS-232 Channel | 1 × Terminal Block (3-pole, Green) |
| Unit To Unit Connectors | 1 × RJ-45 Female |
| Power Connectors | 1 × Terminal Block (2-pole, Green) |
| Power Consumption | DC 5V: 1.749W |
| Operating Temperature | 0°C - 40°C |
| Storage Temperature | -20°C - 60°C |
| Humidity | 0% - 80% RH, Non-condensing |
| Housing | Metal |
| Weight | 0.17 kg |
| Dimensions (L × W × H) | 6.86 × 4.44 × 4.10 cm |
| Faceplate Dimension (L × W × H) | 8.60 × 8.60 × 1.60 cm |
*เช็ค Stock และราคากับเจ้าหน้าที่ก่อนสั่งซื้อทุกครั้ง
เช็ค Stock และราคากับเจ้าหน้าที่ : Audiovideomed Audiovideomed
