KLIPSCH KLIPSCHORN AK7
จำนวน
คำอธิบายสินค้าแบบย่อ
Klipsch Klipschorn AK7 ลำโพงฮอร์นระดับไฮเอนด์ 100W ให้เสียงทรงพลังความละเอียดสูง เหมาะสำหรับเซ็ตอัพห้องฟังเพลง โฮมเธียเตอร์ขนาดใหญ่ หรือสตูดิโอ
KLIPSCH KLIPSCHORN AK7
Description:
For over 75 years, the Klipschorn has defined high-efficiency home audio. The first Klipsch speaker ever produced, and in continuous production longer than any other, the Klipschorn is the legendary manifestation of Paul W. Klipsch's approach to sound. Designed to bring the power, detail, and emotion of live music of the concert hall into the living room, the iconic Klipschorn is experiencing a renaissance in the modern era.
The AK7 was meticulously engineered with an optional Heritage Active Crossover in mind, tuned specifically by master acoustician and PWK protégé Roy Delgado. Featuring a 3-way fully horn-loaded design, extended phase plug, 3" compression driver, and Tractrix midrange horn with Mumps technology, it delivers exceptional efficiency, minimal distortion, and rich bass performance.
Built with premium veneered MDF and 1/2" plywood, the Klipschorn AK7 represents the pinnacle of horn-loaded acoustic engineering and artisanal craftsmanship.
Features:
3-Way Fully Horn-Loaded System - generates greater acoustic power with less wattage for crystal clear sound and minimal distortion.
Optional Heritage Active Crossover - tuned by Roy Delgado to align time and phase while boosting frequencies and balancing EQ for a flat, color-free response.
Extended Phase Plug - paired with the K-771 compression driver to prevent cancellations and equalize wavelengths for cleaner dispersion and clarity.
3" Compression Driver (K-1133-HP) - increases sound pressure to the horn's throat for more voluptuous volume and power.
Tractrix Midrange Horn with Mumps Technology - K-406M patented horn features a shorter 2" throat and small contours to maintain frequency response to the horn's edge.
Deep Bass Performance - fully enclosed low-frequency horn paired with the powerful K-33-E 15" woofer for deep, rich bass with remarkable clarity and impact.
Redesigned I/O Panel - includes passive and active inputs and a passive output relocated to the back for a cleaner look.
Specifications:
| Specification | Klipschorn AK7 Values |
|---|---|
| Frequency Response | Passive: 34Hz - 19kHz (+/-4 dB, 1/8 space anechoic) Active: 34Hz - 20kHz (+/-2.5 dB, 1/8 space anechoic) |
| Sensitivity | 103 dB, Pink noise, 2.83V, 1m (34 Hz - 19 kHz) |
| Power Handling (Cont / Peak) | 100W / 400W |
| Maximum SPL | 120 dB, pink noise, 1m, 20v (34 Hz - 19 kHz) |
| Nominal Impedance | 8 ohms, 4 ohm minimum at 50 Hz |
| Crossover Frequency | 380 Hz, 2900 Hz |
| High Frequency Driver | K-771 compression driver with extended phase plug on a K-792 horn |
| Midrange Driver | K-1133-HP 3" compression driver on a K-406 (K-406M Tractrix) horn |
| Low Frequency Driver | K-33-E 15" woofer in a fully horn loaded system |
| Enclosure Material | Veneered MDF, 1/2" Plywood |
| Inputs | 5-way metal binding post (Passive & Active inputs, Passive output) |
| Dimensions (H × W × D) | 53.25 × 31.5 × 28.125 in (135.25 × 80 × 71.5 cm) |
| Weight | 260 lbs (118 kg) |
| Finish Options | American Auburn, Black Ash, American Walnut |
| Grille Cloth | Silver Metallic |
