Description:
The T-208S is a ceiling subwoofer built-in 70v/100v transformer[cite: 26]. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers[cite: 26]. The subwoofer is designed with power switch to let end-user choose low impedance input 8Ω or high impedance input 100V or 70V, so it is both suitable for bass strengthen use[cite: 26].
The subwoofer works together with the passive loudspeaker like T-208 or T-208CW would be superior union for bar, disco, entertainment & karaoke application where have a strict requirements of bass response[cite: 26].
The built-in 8" speaker driver is designed of wide frequency response 60-2kHz, the multiple power taps 3.8W, 7.5W, 15W, 30W & 60W are helpful for different applications varies from room size and ambient noise surroundings[cite: 26]. The metal grille, ABS baffle and ABS back cover are painted in attractive white color[cite: 26]. Its flush mount type makes the easy and secure installation[cite: 26].
Features:
6.5" ceiling mount type subwoofer[cite: 26]
Specially design for low frequency strengthen use[cite: 26]
Perfect to match with ceiling speakers to set up stereo sound system[cite: 26]
Powerful 60W bass response for wide back cover space[cite: 26]
Venthole helps breath[cite: 26]
Power switch among versatile input 100, 70V & 8Ω[cite: 26]
ABS back covers helps better frequency response[cite: 26]
Metal grille, ABS baffle and ABS back cover[cite: 26]
Easy and secure flush mount installation[cite: 26]
Specifications:
| Model | T-208S[cite: 26] |
| Power Taps @100V | 3.8W, 7.5W, 15W, 30W, 60W[cite: 26] |
| Power Taps @70V | 1.9W, 3.8W, 7.5W, 15W, 30W[cite: 26] |
| Input | 70V/100V/8Ω[cite: 26] |
| Impedance | Com/2.6KΩ/1.3KΩ/670Ω/330Ω/165Ω[cite: 26] |
| SPL(1W/1M) | 90dB[cite: 26] |
| Max. SPL (Rated W/1M) | 107dB[cite: 26] |
| Frequency Response (-10dB) | 60-2KHz[cite: 26] |
| Finish | Baffle: Steel, White Grille: Steel, White[cite: 26] |
| Speaker Driver | 6.5" x 1[cite: 26] |
| Cutout Size | 250mm[cite: 26] |
| Dimensions | 280 x 190mm[cite: 26] |
| Weight | 3.5Kg[cite: 26] |
| Mounting | Flush-mount dog ears[cite: 26] |
